• Model NO.：HX-360D
• Computerized：Computerized
• Cutting Length：0.1-9999.9mm
• Cutting Width：1-360mm,1-500mm
• Voltage：220,380V
• Power：750W,1200W
• Net Weight：260kg,280kg
• Gross Weight：280kg,300kg
• Dimension：180*920*1070mm,980*1450*1300mm
• Transport Package：Plywood Case
• Specification：CE, ISO
• Trademark：HEXIN
• Origin：Kunshan Jiangsu China
• HS Code：845150000
• Production Capacity：100 Sets,Month

Hexin 360D Microcomputer Belt Cutting Machine(cold/hot model)Configuration listModel:HX-360DMicrcomputer sheet  cutting machneItemDescriptionQtyUnwinding departmentunwinding shelf1setGuiding departmentguiding shaft 3 setsfixture lines                                                                                       4 sets            Feeding departmentfeeding rubber coil      1setcontrol pressure spring                   1setlift rail1setCutting departmentlower  knife1setupper knife1 set            Safty departmentprotective cover  1 set    safe senser         1 set    safety fuse1setPhotoelectric departmentphotoelectric marking1 setLubrication departmenttwo mechanical movements parts                       2 seriesCooling departmentfans    2 setsPLC control departmenttouch screen 1 set   switch   5 sets         counts sensor                  1 setCircuitry departmentsevro motor1 set

Machine Features:

1. Max material width: 360mm/500mm;
2. Tolerance: 0.05mm, Precision: 0.1mm;
3. Material thickness range: 0.5mm-15mm;
4. Kiss-cut or cut-through is available;
5. Cut-through is for standard machine, and kiss-cut is an option;
6. This machine employs HMI and PLC system;
7.  It adopts an imported photoelectric tracing device to position, reducing errors.
8. High accuracy and efficiency;
9. Operation is easy;
10. Waste rate is low;
11. Holding CE and ISO Certifications;
12. Manufacturing experience: 10 years;
13. Export experience: 5 years.

Application:
Size cutting for printed material, conductive fabric, foam, diffuser, reflector film, double-sided adhesive tape, nickel plate, PEC, PC, PE, insulation paper, copper/aluminum foil, release paper and all kinds of adhesive tapes.

Our Services:

1. A warranty period of 12 months;
2. A prompt reply within 24 hours;
3. Free operation training before delivering.

Machine Display:


FAQ:
1. Q: Are you a manufacturer or trading company?
A:We are a manufacturer.
2. Q: Where is your factory located in? How can I visit there?
A:Our factory is located in Building 9, No. 157, Wulian Road, Yushan Town, Kunshan, Suzhou City, Jiangsu Province, China (Mainland). You can fly to Shanghai airport directly. We warmly welcome all our clients from home and abroad to visit us!
3. Q: What are your main products ?
A: Our main products are slitting machines, sheeting machines, laminating machines and Die cutting machines.
4. Q: Which industries are your machines widely used in ?
A: All industries need to cut (include full cutting and kiss-cutting), slice, laminate, rotary die cut raw materials can use our machines.
5. Q: How does your factory do regarding quality control?
A: Quality is priority. We control the quality of our products strictly, from the incoming materials to the finished products. Our factory has obtained CE & ISO Certification.
6. Q:If there are no machines available from your list, could  we customize  non-standard machines  from you ?
A: Yes, we have our own professional design engineers, and can customize products according to your requirements.
