Post-Press Equipment

High Speed Hobbing Cutter Roll to Sheet Sheeter China Manufacturer

Wenzhou Snda Machinery Co., Ltd.
  • Classification:Flat Knife Cutter
  • Driven Type:Mechanical
  • Type:Industrial Cutter
  • Blade Material:Steel
  • Computerized:Computerized
  • Voltage:1,2,3 Phase, 220,380V, 50Hz

Base Info

  • Model NO.:HQ-H1400
  • Power:25kw
  • Weight:11000kgs
  • Certification:CE
  • Warranty Period:1 Year
  • Max.Width of Material:1400
  • Max.Cutting Length:1600mm
  • Max.Diameter of Roll:1650mm
  • Material:Paper
  • Transport Package:Wooden Box
  • Specification:12000*3900*2300mm
  • Trademark:SNDA, OEM
  • Origin:Wenzhou, China
  • HS Code:8441100000
  • Production Capacity:10 Sets Per Month

Description

Basic Info.

Model NO. HQ-H1400 Power 25kw Weight 11000kgs Certification CE Warranty Period 1 Year Max.Width of Material 1400 Max.Cutting Length 1600mm Max.Diameter of Roll 1650mm Material Paper Transport Package Wooden Box Specification 12000*3900*2300mm Trademark SNDA, OEM Origin Wenzhou, China HS Code 8441100000 Production Capacity 10 Sets Per Month

Product Description

Hob Cutter type servo-driven paper roll to sheet cutting machine-Two rolls(reels) Feeding

ModelHQ-H1400HQ-H1700
Reference weight of cutting paper50-500g/m250-500g/m2
Max.Diameter of paper1650mm(65")Max1650mm(65")Max
Max.Width of paper1400mm(55")Max1700mm(67")Max
Total power25KW28KW
Cutting length400-1600mm400-1600mm
Cutting accuracy+/-0.4mm+/-0.4mm
Maximum cutting speed300cuts/min300cuts/min
Maximum cutting meter speed300m/min300m/min
Atmospheric pressure0.8MPa0.8MPa
Power supplyAC380V/220Vx50HZAC380V/220Vx50HZ
Total weight11000kg13000kg
Dimensions12m×3.9m×2.35m12m×4.2m×2.35m

Technical Information

Field public facilities

   1. Compressed air to the maximum pressure80psi(3KW,0.8MPA);
   2. AC power supply for three-phase380V,50Hz;DC power supply24V,AC;
   3. Pressure regulator
:380V / 50KW;

   4. Cable:16mm²(three-phase line);
   5. Ground load demand:2000kg/m²
   6. Equipment operating environment temperature between 5 degrees Celsius to 40 degrees Celsius;

Automatic Roll Unwinding Unit

  Automatic Roll Unwinding Unit is Equipped with Hydraulic Shaftless Roll Stands two clamps and Braking system, which are Easy-to-use During Roll Manipulations

Prevent curling system

  Adjusting the roll paper due to the curl of the paper, make the paper smooth after cutting.

Knife holder and Cutting blade

  A total of two knives, one fixed on the base ,the other is on the holder for rolling cutting.
