Sheet Material Printing Single Side Auto Dust-Collecting Machine Labor Save Improve Production Efficiency

Shenzhen Subit Technology Co., Ltd.
  • Cleaning Method:Single Side Clean
  • Effective Cleaning Width (Face mm):Width of Cleaning Material <=400*600mm
  • Material Cleaning Thickness Range:0.08mm-3.0mm
  • Power:220V,50Hz 150W
  • Transport Package:Non-Wooden Case
  • Specification:1050MM X 600MM X 1350MM

Base Info

  • Model NO.:SBT-ZF-CH001
  • Trademark:sUBIt
  • Origin:China
  • HS Code:8420100090
  • Production Capacity:20,Month

Description

Basic Info.

Model NO. SBT-ZF-CH001 Trademark sUBIt Origin China HS Code 8420100090 Production Capacity 20/Month

Product Description

Single side auto dust-collecting machine
(with half auto printing machine,labour-save, and easy to move to half auto equipment)

Model Type: SBT-ZF-CH001
Application: sheet material PET/PC Single side auto dust collecting equipment.(0.08-0.35mm thickness material)
Function: labour save,improve working efficiency(no need dust collecting by manual, press even,excellent effect of dust away, back stick, make sure every prints is clean effect.
Sheet Material Printing Single Side Auto Dust-Collecting Machine Labor Save Improve Production Efficiency


The traditional processing:
Sheet Material Printing Single Side Auto Dust-Collecting Machine Labor Save Improve Production Efficiency

Parameters:
Cleaning method

Single side clean
Effective cleaning width (face mm)width of cleaning material <=400*600mm
Material cleaning thickness range 0.08mm-3.0mm
Dust paper rollknife-free PP sticky paper roll (optional)
Static elimination methodElectrostatic ion wind static elimination device (air volume adjustable)
Operating speed  0~1000 times/hour, text adjustable
Operating modeAutomatic dust removal by the inductive switch, taking the material sensing to the switch repeat.
ElectricityChina Zhengtai
Power220V/50HZ 150W
CylinderTaiwan Yadeke
MotorTaiwan Oriental
Sensor / push button switchJapen Omron

Features: (independent R&D, patent application)

1. Adopting Japan's dust-removing roller cleaning technology and sticky dust (contact with material) rubber roller, it can quickly remove surface dust and impurities;
2. The dust removal adopts the floating cylinder to make the descending dust removal pressure consistent, stable, quiet and no noise.
3. PLC programming control, the performance is more stable;
4. Dust collection by dust collecting roller, the dust collecting roller is a peelable dust collecting paper roll (collecting and transferring dust particles) as a daily consumable material, and can be used with a knife-free (printing line) dust collecting paper roll, which greatly improves work efficiency. Excellent cleaning performance;
5. Using electrostatic ion fan, completely eliminate static interference, easy dust removal, and reduce secondary pollution;
6. The power drive system is a Taiwan stepper motor with stable operation;
7. Text mode sets the length and number of dust removal products, which is better and easier;


Exporting method
Sheet Material Printing Single Side Auto Dust-Collecting Machine Labor Save Improve Production Efficiency

Aftersale service:

1)Machine warranty period: 12 month, factory would supply spare parts on free in warranty time.
2) Technical supporting in lift time. Any problems happened, factory would response in 8hours via Email, instant message or phone directly.
