• Model NO.：FC690920
• Computerized：Computerized
• Automatic Grade：Automatic
• Application：Paper Packaging Materials, Stickers Products, Heat Insulation Material, Insulating Materials
• Max Cutting Speed：700mm,S
• Max Cutting Force：1500g
• Blade Types：Blade, Creasing Tool and Pen
• Actual Dimensions：1286.5mm*1228mm*1000mm
• Media Hold Method：Vacuum Suction
• Cutting Control System：Digital Servo System
• Maximum Cutting Size：700mm*990mm
• Package Dimensions：1568mm*1356mm*620mm
• Positioning Sensor Type：CCD Digital Camera
• Gw：151kg
• Working Voltage：110-240V 50,60Hz
• Max Arms Contour Cutting Area：690mm*920mm
• Power：1.3kw
• Interface：USB,Network Cable
• Certification：CE, SGS, RoHS, Is09001
• Transport Package：Wooden Package
• Specification：1286.5mm*1228mm*1000mm
• Trademark：saga
• Origin：Hefei China
• HS Code：84411000
• Production Capacity：10000PCS

Detailed PhotosProduct ParametersMachine performanceMedia hold methodVacuum suctionPositioning sensor typeDigital camera(CCD)Maximum cutting size700mm×990mmMaximum ARMS Contour Cutting Size690mm×920mmScanning speed5-10sSoftware and compatibilityPower and working envionment requirementsVoltage and current100VAC-120VAC.50/60Hz,Maximum current 6.8A
200VAC-240VAC,50/60Hz,Maximum current 3.4APower350WVoltage and current(Vacuum Pump)110VAC, 50Hz, Rated current 12.4A, 60Hz, Rated current 17.2A
220VAC, 50Hz, Rated current  6.2A,60Hz, Rated current 8.6APower(Vacuum Pump)50Hz, 1.1KW;60Hz,1.3KWStandIncludedOperation environmentTemperature+5ºC to +35ºC(Fahrenheit 41-95),Humility 30%-75%(Non-condensing)Dimensions and weightsActual dimensions1286.5mm*1228mm*1000mmPackage dimensions1568mm*1356mm*620mmGW151kg
