Digital Servo Motor Label Stickers Vinyl Kiss Cutter Plotter
Hefei Saga Computer Numerical Control Co., Ltd.- After-sales Service：Lifetime Service
- Warranty：1 Year
- Species：Die Cutting and Creasing Machine
- Imprinting Type：Rotary Platen
- Placing Form of Template：Horizontal
- Die Cutting Tool：Steel Blade
Base Info
- Model NO.：SG-B720IIP
- Computerized：Computerized
- Automatic Grade：Automatic
- Application：Stickers Products, Heat Insulation Material, Insulating Materials, Dust-proof Material
- Software：Dragoncut
- Maximum Liner Cutting Speed：960mm,S
- Maximum Cutting Force：750g
- Power：150W
- Transport Package：Wooden Package
- Specification：930mm*250mm*260mm; 25.0Kg
- Trademark：Saga
- Origin：China
- HS Code：8479899990
- Production Capacity：10000pieces,Year
Description
Overview
You might also likeProduct DescriptionApplication
Product ParametersModel Name SG-B720II/B720IIP SG-B1400II/B1400IIP SG-B1800II/B1800IIP Maximum Sheet Size 720mm 1400mm 1800mm Maximum Cutting Size 630mm 1260mm 1680mm Minimum Cutting Character About 5mm2 Mechanical Resolution 0.02mm Repeat Precision 0.082mm Maximum Liner Cutting Speed 960mm/s Maximum Cutting Force 750g Cutting Control System DC Servo Motor Speed 0-3000RPM CPU 64-DSP Package dimensions 1030mm*350mm*490mm 1710mm*350mm*490mm 2100mm*400mm*550mm Actual dimensions 930mm*250mm*260mm 1610mm*250mm*260mm 2010mm*250mm*260mm Gross/Net Weight 27.8kg/25.0kg 42.0kg/35.0kg 68.0kg/47.0kg Connectivity USB/RS-232 Software & Compatibility DragonCut, compatible for Windows7,8,10(USB direct connection to the computer)
Corel Draw/Illustrator Plug-in(SD direct connection to the computer) Power Source 100V~240V,50/60Hz Power 150W Operation environment Temperature: +5ºC - +35ºC/41ºF - 95ºF Humility:30%-75% Stand & Pocket Included Included Included
Certifications Packaging & Shipping
Filed:Detailed Photos
Product Parameters
Corel Draw/Illustrator Plug-in(SD direct connection to the computer)
Certifications Packaging & Shipping
Exhibition
