Auto Sheet Feeding Flatbed Cutter
Hefei Saga Computer Numerical Control Co., Ltd.- After-sales Service：Lifetime Service
- Warranty：1 Year
- Species：Die Cutting and Creasing Machine
- Imprinting Type：Rotary Platen
- Placing Form of Template：Horizontal
- Die Cutting Tool：Steel Blade
Base Info
- Model NO.：FC 4866B
- Computerized：Computerized
- Automatic Grade：Automatic
- Application：Paper Packaging Materials, Stickers Products, Heat Insulation Material, Insulating Materials
- Max Cutting Speed：600mm,S
- Max Cutting Force：960g
- Blade Types：Blade, Creasing Tool and Pen
- Media Hold Method：Vacuum Suction
- Cutting Control System：Digital Servo System
- Maximum Cutting Size：330mm*483mm
- Max Arms Contour Cutting Area：485mm*660mm
- Power：1100W
- Actual Dimensions：2390mm*1005mm*1235mm
- Gw/Nw：234.6kg,136kg
- Interface：USB
- Package Dimensions(Cutting Platform)：2390mm*1005mm*1235mm
- Package Dimensions(Feeding Platform)：915mm*865mm*1400mm
- Working Voltage：110-240V 50,60Hz
- Certification：CE, SGS, RoHS, Is09001
- Transport Package：Wooden Package
- Specification：2390mm*1005mm*1235mm
- Trademark：saga
- Origin：Hefei China
- HS Code：84411000
- Production Capacity：10000PCS
Description
Overview
You might also like Product Description
ApplicationExhibition
Certifications
Auto Feeding Sheet Die Cutter Flatbed Cutting Plotter for Flexible Packaging
Detailed Photos
ApplicationProduct Parameters
Certifications
