Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)

Hefei Saga Computer Numerical Control Co., Ltd.
  • After-sales Service:Lifetime Service
  • Warranty:1 Year
  • Species:Die Cutting and Creasing Machine
  • Imprinting Type:Rotary Platen
  • Placing Form of Template:Horizontal
  • Die Cutting Tool:Steel Blade

Base Info

  • Model NO.:CPC1800IIP
  • Computerized:Computerized
  • Automatic Grade:Automatic
  • Application:Stickers Products, Heat Insulation Material, Insulating Materials, Dust-proof Material
  • Software:Dragoncut
  • Maximum Liner Cutting Speed:960mm,S
  • Maximum Cutting Force:750g
  • Power:150W
  • 1800mm:1680mm
  • Minimum Cutting Character:About 5mm2
  • Mechanical Resolution:0.02mm
  • Repeat Precision:0.082mm
  • Cutting Control System:DC Servo
  • Transport Package:Wooden Package
  • Specification:2010mm*230mm*285mm; 68.0Kg
  • Trademark:Saga
  • Origin:China
  • HS Code:8479899990
  • Production Capacity:10000pieces,Year

Description

Overview Product Description

Product ParametersModel NameSG-C720II/BC720IIPSG-BC1400II/C1400IIPSG-C1800II/C1800IIPMaximum Sheet Size720mm1400mm1800mmMaximum Cutting Size630mm1260mm1680mmMinimum Cutting CharacterAbout 5mm2Mechanical Resolution0.02mmRepeat Precision0.082mmMaximum Liner Cutting Speed960mm/sMaximum Cutting Force750gCutting Control SystemDC ServoMotor Speed0-3000RPMCPU64-DSPPackage dimensions1030mm*350mm*490mm1710mm*350mm*490mm2100mm*400mm*550mmActual dimensions930mm*250mm*260mm1610mm*230mm*285mm2010mm*230mm*285mmGross/Net Weight27.8kg/25.0kg42.0kg/35.0kg68.0kg/47.0kgConnectivityUSB/RS-232Software & CompatibilityDragonCut, compatible for Windows7,8,10(USB direct connection to the computer)
Corel Draw/Illustrator Plug-in(SD direct connection to the computer)Power Source100V~240V,50/60HzPower150WOperation environmentTemperature: +5ºC - +35ºC/41ºF - 95ºF Humility:30%-75%Stand & PocketIncludedIncludedIncluded

This Parameter is subject to change without prior notice.The company reserves the right of the final interpretation.

Certifications

Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)

Packaging & Shipping

Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)

FAQ

Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)Optical Sensor Contour Sticker Cut Machine Saga Chinese Laser Factory Film Vinyl CAD Cutter Cutting Plotter (CPC1800IIP)
