FC4560A Cut and Crease Flatbed Cutting Plotter Die Cutter

Hefei Saga Computer Numerical Control Co., Ltd.
  • After-sales Service：Lifetime Service
  • Warranty：1 Year
  • Species：Die Cutting and Creasing Machine
  • Imprinting Type：Rotary Platen
  • Placing Form of Template：Horizontal
  • Die Cutting Tool：Steel Blade

Base Info

  • Model NO.：SG-FC4560A
  • Computerized：Computerized
  • Automatic Grade：Automatic
  • Application：Paper Packaging Materials, Stickers Products, Heat Insulation Material, Insulating Materials
  • Max Cutting Speed：600mm,S
  • Max Cutting Force：510g
  • Blade Types：Blade, Creasing Tool and Pen
  • Media Hold Method：Vacuum Suction
  • Cutting Control System：Digital Servo System
  • Maximum Cutting Size：467mm*629mm
  • Max Arms Contour Cutting Area：457mm*609mm
  • Actual Dimensions：875mm*990mm*310mm
  • Package Dimensions：1230mm*1000mm*460mm
  • Gw/Nw：85kg,47kg
  • Working Voltage：110-240V 50,60Hz
  • Power：600W
  • Interface：USB
  • Certification：CE, SGS, RoHS, Is09001
  • Transport Package：Wooden Package
  • Specification：875mm*990mm*310mm
  • Trademark：saga
  • Origin：Hefei China
  • HS Code：84411000
  • Production Capacity：10000PCS

Description

Software and compatibilityPower and working envionment requirementsPower source100V-240V 50/60 HzPower600WOperation environmentTemperature +5ºC to +35ºC(Fahrenheit41-95),Humility 30%-75%(Non-condension)StandOpticalThis parameter is subject to change without prior notice. The company reserves the right of final interpretation
 FC4560A Cut and Crease Flatbed Cutting Plotter Die CutterFC4560A Cut and Crease Flatbed Cutting Plotter Die CutterFC4560A Cut and Crease Flatbed Cutting Plotter Die Cutter
FC4560A Cut and Crease Flatbed Cutting Plotter Die Cutter
