High Speed Vinyl Cutting Plotter 720 with Servo Motor

Hefei Saga Computer Numerical Control Co., Ltd.
  • After-sales Service：Lifetime Service
  • Warranty：1 Year
  • Species：Die Cutting and Creasing Machine
  • Imprinting Type：Rotary Platen
  • Placing Form of Template：Horizontal
  • Die Cutting Tool：Steel Blade

Base Info

  • Model NO.：SG-C720IIP
  • Computerized：Computerized
  • Automatic Grade：Automatic
  • Application：Stickers Products, Heat Insulation Material, Insulating Materials, Dust-proof Material
  • Software：Dragoncut
  • Maximum Liner Cutting Speed：960mm,S
  • Maximum Cutting Force：750g
  • Power：150W
  • Transport Package：Wooden Package
  • Specification：930mm*250mm*260mm; 28.0Kg
  • Trademark：Saga
  • Origin：China
  • HS Code：8479899990
  • Production Capacity：10000pieces,Year

Description

About 5mm2Mechanical Resolution0.02mmRepeat Precision0.082mmMaximum Liner Cutting Speed960mm/sMaximum Cutting Force750gCutting Control SystemDC ServoMotor Speed0-3000RPMCPU64-DSPPackage dimensions1030mm*350mm*490mm1710mm*350mm*490mm2100mm*400mm*550mmActual dimensions930mm*250mm*260mm1610mm*230mm*285mm2010mm*230mm*285mmGross/Net Weight27.8kg/25.0kg42.0kg/35.0kg68.0kg/47.0kgConnectivityUSB/RS-232Software & CompatibilityDragonCut, compatible for Windows7,8,10(USB direct connection to the computer)
Corel Draw/Illustrator Plug-in(SD direct connection to the computer)Power Source100V~240V,50/60HzPower150WOperation environmentTemperature: +5ºC - +35ºC/41ºF - 95ºF Humility:30%-75%Stand & PocketIncludedIncludedIncludedThis Parameter is subject to change without prior notice.The company reserves the right of the final interpretation.
