• Model NO.：WJJM-350
• Application：Paper Packaging Materials, Stickers Products, Heat Insulation Material, Dust-proof Material, Iml and Thin Film
• Max Die Cutting Area：340*340mm (W*L)
• Repeat Length of Die Cutting：60 mm~350 mm
• Max Speed(Semi Rotary Die Cutting)：300 Times,Min
• Max Full Rotary Speed：110 Meters,Min
• Accuracy of Adhesive Cutting：Plus and Minus 0.15 mm
• Paper Width：100-350 mm
• Magnetic Cylinder：120 Teeth 1,8" Cp
• Transport Package：Steel Pallet and Wooden Boxes
• Specification：2800*1300*1800 mm
• Trademark：WANJIE
• Origin：China
• Production Capacity：5 Sets,Month

Basic Info.

Model NO. WJJM-350 Application Paper Packaging Materials, Stickers Products, Heat Insulation Material, Dust-proof Material, Iml and Thin Film Max Die Cutting Area 340*340mm (W*L) Repeat Length of Die Cutting 60 mm~350 mm Max Speed(Semi Rotary Die Cutting) 300 Times/Min Max Full Rotary Speed 110 Meters/Min Accuracy of Adhesive Cutting Plus and Minus 0.15 mm Paper Width 100-350 mm Magnetic Cylinder 120 Teeth 1/8" Cp Transport Package Steel Pallet and Wooden Boxes Specification 2800*1300*1800 mm Trademark WANJIE Origin China Production Capacity 5 Sets/Month

Product Description

Our belief
We are creating the first band of Chinese label machine with all strength.


Characteristics

WJJM 350A multi-function intermittent rotary label cutting machine is researched and developed by Wanjie Machinery Equipment Co., Ltd, which is used for printed label processing. The machine is module design, which adopts rotary die-cutting mode. It can realize In-mould-label, copper printing paper label full cutting (have automatic convey and collection platform) and adhesive paper intermittent cutting, can exchange between this two ways. The machine can use for adhesive label intermittent cutting or full rotary cutting, also can use for IML, copper printing paper label full cutting. Can equipped with flexo spot varnishing, full-plate varnishing, UV glue laminating, spot cold stamping, inkjet code, slitting, longitudinal cutting and reverse laminating, etc.

Technical Variables

Max speed(Semi Rotary Die Cutting)	300 times/min
Max full rotary speed	110 meters/min
Accuracy of adhesive cutting	plus and minus 0.15 mm
Max die cutting area	340*340mm (W*L)
Paper width	100-350 mm
Max unwinding diameter	700 mm
Max rewinding diameter	700 mm
Magnetic cylinder	120 teeth1/8''  CP
Repeat length of die cutting	60 mm~350 mm
Motor power	10.75 kw
Overall dimension	2800*1300*1800 mm
Weight	About 3000 kgs



Optional Function


After Sale Service
--Machine Test Video Before Delivery,
--English Manual
-- Electric Diagram
--Machine Picture
--Supply of spare parts
-- Installations
--24hous Hot line Service
--Technical Training


Fair show

About US
Hebei Wanjie Machinery Technology Co.,Ltd founded in 1999, is lodacted in northern China printing machinery production base-Yutian City. We have more than 100 employees and 4000 square meters building.
We are one of the leader manufacture for label machinery, our CE standard products have offset ,letterpress, flexo label printing machine, label die cutting , slitting , inspection, rewinding machines.

We have own CNC workshop to make machine body structure and parts accessories which ensure the quality and accuracy
